型 號 | 換熱量 DT=7K | 風(fēng) 機 | 翅片片距 | 沖霜水量 | 重量 | ||||
風(fēng)量 | 直徑 | 射程 | 功率 | 電壓 | |||||
KW | m3/h | mm | m | w | V | mm | m3/h | kg | |
DLS17/402A | 17 | 7000 | 400 | 13 | 2×180 | 380 | 4.5 | 1.9 | 181 |
DLS25/452A | 25 | 9000 | 450 | 17 | 2×250 | 380 | 2.7 | 203 | |
DLS29/453A | 29 | 13500 | 450 | 17 | 3×250 | 380 | 3.1 | 270 | |
DLS36.5/503A | 36.5 | 18000 | 500 | 19 | 3×450 | 380 | 3.7 | 297 | |
DLS42/503A | 42 | 18000 | 500 | 19 | 3×450 | 380 | 4.3 | 340 | |
DLS49/503A | 49 | 18000 | 500 | 19 | 3×450 | 380 | 4.9 | 385 | |
DLS59/504A | 59 | 24000 | 500 | 19 | 4×450 | 380 | 6.1 | 420 | |
DLS70/554A | 70 | 30000 | 550 | 25 | 4×600 | 380 | 7.3 | 510 | |
DLS84/554A | 84 | 30000 | 550 | 25 | 4×600 | 380 | 7.7 | 530 | |
DDS11/402A | 11 | 7000 | 400 | 13 | 2×180 | 380 | 6.0 | 1.5 | 176 |
DDS15.5/452A | 15.5 | 9000 | 450 | 17 | 2×250 | 380 | 2 | 196 | |
DDS19/453A | 19 | 13500 | 450 | 17 | 3×250 | 380 | 2.4 | 265 | |
DDS24/503A | 24 | 18000 | 500 | 19 | 3×450 | 380 | 2.9 | 285 | |
DDS29/503A | 29 | 18000 | 500 | 19 | 3×450 | 380 | 3.4 | 330 | |
DDS32/503A | 32 | 18000 | 500 | 19 | 3×450 | 380 | 3.9 | 375 | |
DDS38/504A | 38 | 24000 | 500 | 19 | 4×450 | 380 | 4.8 | 385 | |
DDS47/554A | 47 | 30000 | 550 | 25 | 4×600 | 380 | 6.1 | 440 | |
DDS58/554A | 58 | 30000 | 550 | 25 | 4×600 | 380 | 6.5 | 460 | |
DJS7.8/402A | 7.8 | 7000 | 400 | 13 | 2×180 | 380 | 9.0 | 1.1 | 172 |
DJS11.5/452A | 11.5 | 9000 | 450 | 17 | 2×250 | 380 | 1.3 | 195 | |
DJS14/453A | 14 | 13500 | 450 | 17 | 3×250 | 380 | 1.7 | 256 | |
DJS17/503A | 17 | 18000 | 500 | 19 | 3×450 | 380 | 2.1 | 277 | |
DJS20/503A | 20 | 18000 | 500 | 19 | 3×450 | 380 | 2.5 | 320 | |
DJS23/503A | 23 | 18000 | 500 | 19 | 3×450 | 380 | 2.9 | 363 | |
DJS26/504A | 26 | 24000 | 500 | 19 | 4×450 | 380 | 3.5 | 396 | |
DJS31/554A | 31 | 30000 | 550 | 25 | 4×600 | 380 | 4.3 | 484 | |
DJS40/554A | 40 | 30000 | 550 | 25 | 4×600 | 380 | 5.3 | 506 |
